Captive Aire Systems DU50HFA High Speed Roof Mounted Restaurant Exhaust Fan Tested & Working
USED
Captive Aire Systems
CAS-DU50HFA-Grease
Centrifugal Upblast Direct Drive DU50HFA Roof Mounted Restaurant Duty (UL 762) 0.5 HP 1200 CFM @0.5 in. w.c.
DU50HFA High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control, disconnect switch and 13-3/4" wheel. Exhaust Fan handles 1200 CFM @ -0.500" wc ESP. Fan runs at 1278 RPM. Exhaust Motor: 0.500 HP, 1 Phs, 115 V, 60Hz, 6.3 FLA, TEAO-ECM (Totally Enclosed Air Over Electronically Commutated Motor)
Includes MSC Controller for manual or 0-10V speed control.
Includes grease cup for kitchen-duty centrifugal exhaust fans (part #GC-CUF). The dimensions of the grease cup are 17-1/8 L X 5-1/16 W X 3-3/4 H (20 GA.) It includes the down spout.
Includes standard hinge kit (part # HBKIT-01) for exhaust fan roof curbs. Includes hardware to attach hinge to curb and hinge to base. The hinge kit ships loose. It is used on fans with wheels 20 inches or smaller. 12 GA Galvanized
HP: 0.5
Phase: 1
Motor Type: ECM
Voltage: 115
FLA: 6.3
Fan/Motor RPM Range: tel:[phone removed by eBay]
Speed Controller Type: CaptiveAire MSC (Motor Speed Controller)
Exhaust Fan UL Listing: UL 762 (Restaurant Duty)
